LatestProducts
Steel Pipe (304, 316, 316L, 201, 202)
Stainless Steel, Steel Pipe, Stainless Steel Pipe
Description
Basic Info
- Model NO.: 304, 316, 316L, 201, 202, 430, 410s
- Technique: Cold Rolled
- Surface Treatment: Polish and Satin
- Section Shape: Square
- Surface Finish: Satin, Mat, Mirror, Hairline
- Trademark: VLW
- Specification: Thickness Scale: 0.3mm to 3.0mm
- HS Code: 73064000
- Type: Welded
- Material: Stainless Steel
- Usage: Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction & Decoration, Special Purpose
- Length: 6 M or According to Customer′s Demand
- Monthly Output: 5000 Tons
- Transport Package: Poly Bag Inside, Weaving Bag Outside
- Origin: Foshan City, Guang Dong Province
Product Description
Steel Pipe (304, 316, 316L, 201, 202)
1.Stainless Steel Pipe Grade: 201, 202, 430, 410, 409, 304, 304L, 316, 316L.
2..Specification for stainless steel pipe:
Sizes for round stainless steel pipe:
OD(mm):9.5, 12.7, 15.9, 17, 18, 19.1, 20, 21, 22.2, 23, 25.4, 28, 31.8, 35, 38.1, 48, 50.8, 60, 63.5, 63.5, 73, 76.2, 88.9, 101.6, 114, 127, 129, 133, 141, 159, 168, 175, 191, 203, 207.
Sizes for Square Stainless Steel Pipe:
10X10 ; 12X12; 12.7X12.7; 14X14; 15X15; 16X16; 17X17; 18X18; 19X19; 20X20; 23X23; 25X25; 28X28; 30X30; 31.8X31.8; 35X35; 36X36;40X40;50.8*50.8;60X60;80X80;100X100;
Size for Regtangular Stainless Steel Pipe:
20X10 ;23X11;25X13;30X10; 30X15; 30X20; 36X23; 38X25; 40x10; 70x10; 90x10; 40x20; 50x25; 50x30; 60x30; 60x40; 73x43; 75x45; 80x40; 95x45; 50x100; 100x110; 100x120; 120x60; 150x50; 100x150; 40x210; 50x200; 120x130; 150x60
3. Standard of Stainless Steel Pipe: ASTM A554, JIS G3446.
4. Wall thickness for Stainless steel tube: 0.25mm-3mm
5. Surface: 2B, Mirror, Polish, hairline, Satin,No.4.
6. Tolerance:
A)Outer diameter: +/-0.2mm
B)Thickness: +/-10%
C)Length: +/-5mm
7. Application: Structural, decoration (fencing, railing, balcony balustrades, antitheft doors/ windows, gate fittings, staircases, furniture fittings, sanitary wares fittings, kitchen wares fittings, mechanical fittings, tripod for camera, etc)
8. Test: Chemical composition analysis by SPECTROTEST.
1.Stainless Steel Pipe Grade: 201, 202, 430, 410, 409, 304, 304L, 316, 316L.
2..Specification for stainless steel pipe:
Sizes for round stainless steel pipe:
OD(mm):9.5, 12.7, 15.9, 17, 18, 19.1, 20, 21, 22.2, 23, 25.4, 28, 31.8, 35, 38.1, 48, 50.8, 60, 63.5, 63.5, 73, 76.2, 88.9, 101.6, 114, 127, 129, 133, 141, 159, 168, 175, 191, 203, 207.
Sizes for Square Stainless Steel Pipe:
10X10 ; 12X12; 12.7X12.7; 14X14; 15X15; 16X16; 17X17; 18X18; 19X19; 20X20; 23X23; 25X25; 28X28; 30X30; 31.8X31.8; 35X35; 36X36;40X40;50.8*50.8;60X60;80X80;100X100;
Size for Regtangular Stainless Steel Pipe:
20X10 ;23X11;25X13;30X10; 30X15; 30X20; 36X23; 38X25; 40x10; 70x10; 90x10; 40x20; 50x25; 50x30; 60x30; 60x40; 73x43; 75x45; 80x40; 95x45; 50x100; 100x110; 100x120; 120x60; 150x50; 100x150; 40x210; 50x200; 120x130; 150x60
3. Standard of Stainless Steel Pipe: ASTM A554, JIS G3446.
4. Wall thickness for Stainless steel tube: 0.25mm-3mm
5. Surface: 2B, Mirror, Polish, hairline, Satin,No.4.
6. Tolerance:
A)Outer diameter: +/-0.2mm
B)Thickness: +/-10%
C)Length: +/-5mm
7. Application: Structural, decoration (fencing, railing, balcony balustrades, antitheft doors/ windows, gate fittings, staircases, furniture fittings, sanitary wares fittings, kitchen wares fittings, mechanical fittings, tripod for camera, etc)
8. Test: Chemical composition analysis by SPECTROTEST.
| Name | Stainless Steel Tupes&Stainless Steel Pipes | |||||
| Standard | ASTM A554, A249, A269 and A270, A312 | |||||
| Material Grade | 201 ( Ni 0.8%), 202 (Ni 3.5%~4.5%), 301(Ni 5%) 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L (Ni10%~14%), |
|||||
| Outer Diameter | 6mm--159mm | |||||
| Thickness | 0.25mm - 3.0mm | |||||
| Length | 6m or as customers' request | |||||
| Tolerance |
a) Outer Diameter: +/- 0.2mm | |||||
| b) Thickness: +/- 0.02mm | ||||||
| c) Length: +/- 5mm | ||||||
| Surface | 180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish |
|||||
| Application | Decoration construction, upholstery, industry instrument | |||||
| Test | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT | |||||
| Chemical Composition of Material |
Material Composition |
201 | 202 | 304 | 316 | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.08 | ≤0.12 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 16-18 | 17-19 | 18-20 | 16-18 | 16-18 | |
| N | 3.5-5.5 | 4-6 | 8-10.5 | 10-14 | ||
| Mo | 2.0-3.0 | |||||
| Mechanical Property |
Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <253 | <253 | <200 | <200 |
||
